Model: Pulse L120F
Block Material: Copper
Radiator Material: Aluminum
Radiator + Pump Dimensions: 176mm x 123.5mm x 40.5mm
TDP (Thermal Design Power): 200
Pump
Speed: 2800 rpm
Rated Voltage: 12 V
Power Consumption: 8.4 Watts
Noise: 25dBA
Bearing Type: Ceramics Bearing
MTBF: 80000 hrs.
Fan
Speed: 600-1800 rpm
Connector: PWM 4-Pin
Dimension: 120mm x 120mm x 25mm
Bearing Typ: Hydraulic Bearing
Started Voltage: 9 V
Rated Voltage: 12 V
Rated Current: 0.16 A (One Fan)
Power Consumption: 1.92 Watts (One Fan)
Air Pressure: 0.59 – 1.34 mm-H2O
Air Flow: 29.84-71.65 CFM
Noise: 10.5 – 31.8 dBA
Bearing Type: Hydraulic Bearing
MTBF: 60000 hrs.
Socket :
INTEL: LGA 2066/2011-V3/115X/775/1200
AMD: FM1/FM2/AM4/AM3+/AM3/AM2+/AM2
