RIGHT SIDE OPENING PANEL
Vertical motherboard mounting, prevent vga from bending. wind flow faces directly to vga, performs excellent heat dissipation.

BEST CABLE MANAGING
I/O port facing up, allows better cable management, makes it clean and simple.

SUPPORTS 240 RADITOR
Supports 120/240 water cooling and two 120mm fans on rear

DUST PROOF NET QUICK RELEASE
The dust proof nets under the power supply, on the front panel adopts quick release design, makes the cleaning easier. Power supply / Front panel dust proof net.

UPDATE AVAILABLE
User-friendly design is adopted to make it availble to update or expand in PC bulid.

I/O PORT ON TOP
Friendly interface, easy to use and expand.

HDD / SSD AT THE LEFT
The left placement make the best use of the space.

THERMAL SOLUTION
Thermal solution is achieved by excellent internal cooling channel and up to 5 fans can be installed in the PC chassis.

SPECIFICATIONS

Dimensions: 440*215*443mm
Packing Size : 494*284*515mm
Material: Chassis: 0.6mm SPCC
N.W. : 5.93KG
G.W. : 7.05KG
Motherboard : ATX, M-ATX
HDD / SSD : 2 / 2 or 1 / 3
Expansion Slots : 7
Max. VGA Card : 293 / 318mm
Max. CPU Heightr : 167mm
Power Supply : 200mm / Bottom

Cooling System
Front : 120mm*3 / 140mm*2
Rear : 120/240 water-cooling / 120mm*2
Top : 280 water-cooling*1 / 120mm*2, 140mm*2 fan
FRONT I/O : Power / Reset / USB 3.0x2 / HD AUDIO
Front panel : Metal
Right Panel : Tempered glass
