Specifications :

Model : CS-C6N-R200-1Q5WFL
Camera

Image Sensor : 1/3" Progressive Scan CMOS

Shutter Speed : Self-adaptive shutter

Lens : 4mm@F1.6, view angle: 105°(Diagonal), 88° (Horizontal), 46°(Vertical)

Lens Mount : M12

Day & Night : IR-cut filter with auto-switching

DNR : 3D DNR

WDR : WDR
Compression

Video Compression : H.264 / H.265

Video Bit Rate : Adaptive bit rate

Max. Resolution : 3K (2880 × 1620）

Frame Rate : Self-adaptive during network transmission
Network

Smart Alarm : Motion Detection, AI-Powered Human Shape Detection

Wi-Fi Pairing : AP pairing

Protocol : EZVIZ Cloud Proprietary Protocol

Interface Protocol : EZVIZ Cloud Proprietary Protocol
Interface

Storage : Supports microSD card (max. 512 GB)

Power : Type-C

Wired Network : RJ45 × 1 (10 M / 100 M self-adaptive Ethernet port)
Wi-Fi

Standard : IEEE802.11a, 802.11b, 802.11g, 802.11n,

Frequency Range : 2.4 GHz: 2.4 GHz ~ 2.4835 GHz

Channel Bandwidth : 2.4G: Supports 20MHz

Security : WPA/WPA2, WPA-PSK/WPA2-PSK

Transmission Rate : 11b 11Mbps, 11g 54Mbps, 11n MCS7, 11a 54Mbps, 11ac MCS9.11ax MCS11

Output Power (EIRP) : 19 dBm

Antenna Gain : 1.9 dBi
General

Operating Conditions : -10°C to 45°C (14°F to 113 °F )

Humidity 95% or less (non-condensing)

Power Supply : DC 5V / 2A

Power Consumption : Max. 8 W

IR Range : Max. 10 meters (32.81ft)

Dimensions : 88 × 88 × 113 mm (3.46 × 3.46 × 4.45 inch)

Packaging Dimensions : 103 × 103 × 168 mm (4.06 × 4.06 × 6.61 inch)

Net Weight : 222 g (0.49 lb)
In the box

- C6N G1 Camera

- Power Adapter

- Power Cable

- Drill Template

- Mounting Plate

- Screw Kit

- Regulatory Information × 2

- Quick Start Guide
