GP-550
Elegant black PSU casing with full black mesh cables
ATX12V Ver.2.30 compliant with ATX12V Ver.2.31
High efficiency PSU, up to 85% efficiency
Single 12V Rail for high compatibility and extreme high current output
Longer 20 + 4 and 4 + 4 pins up to 550mm is easy for high-end tower chassis installation
14cm silent black fan with smart thermal fan speed control circuit
Full protection functions with OVP / UVP / OPP / SCP / SIP
Safety and EMC certified by CE
ECO friendly by RoHS and Erp 2013 directives

PSU Type ATX
Cabling Wired
Efficiency 85+ Bronze

Specification :
Dimensions: 158mm x 85mm x 150mm (W x H x D)
Input Voltage: 100-240 VAC
Input Current: 3.5-7A
Input Frequency Range: 50-60Hz
PFC: Active PFC (>.99)
Power Good Signal: 100-500 ms
Hold Up Time: >17ms
Efficiency: > 81% (85% max)
MTBF: > 100,000 Hours
Protection: OVP / UVP/ OTP / OCP/ OLP/ OPP/ SCP
Power: 550W
Operation Temperature: 0-40C
Safety: CE / FCC / CB
Cooling: 140mm Ultra Silent Fan
Noise: <25dBa
80 Plus Certified: Yes - 80 Plus Bronze
Manufacturer Part Number: GP-550
EAN Number: 6931858720052
Has Mains Plug: No
Colour: Black
Unit (Product) Dimensions (mm): 150mm x 85mm x 140mm (W x H x D)
Packaging Dimensions (mm): 300mm x 180mm x 115mm (W x H x D)
Net Weight (KGs): 1.6 KGs
Gross Weight (KGs): 2 KGs
