Model : GP-P750GM
Type : Intel Form Factor ATX 12V v2.31
PFC : Active PFC (>0.9 typical)
Input Voltage : 1‎00-240 Vac (full range)
Input Current : 1‎2-6 A
Input Frequency : 6‎0-50 Hz
Output Capacity : 7‎50W
Dimension : 1‎50 x 140 x 86 mm
Fan Type : 1‎20mm Hydraulic Bearing ( HYB ) fan
80 PLUS : Gold
Efficiency : 9‎0% at typical load
MTBF : >100,000 hours
Protection : OVP/OPP/SCP/UVP/OCP/OTP
Power Good Signal : 1‎00-500ms
Hold Up Time : >16ms
Cable Type : Flat, All black
Connectors :
ATX/MB 20+4 Pin x 1 : 610mm*1
CPU/EPS 4+4 Pin x 2 : 600mm*2
PCI-e 6+2 Pin x 4 : 600mm+150mm*2
SATA x 8 : 600mm+150mm+150mm+150mm*2 :
4 Pin Peripheral x 3 + 4-Pin floppy x 1 :
500mm+120mm+120mm+120mm *1
