Socket compatibility :
-Intel LGA2066, LGA2011-0 & LGA2011-3 (Square ILM), LGA1156, LGA1155, LGA1151, LGA1150
-AMD AM2, AM2+, AM3, AM3+, AM4, FM1, FM2, FM2+ (backplate required)
Height (without fan) : 70 mm
Width (without fan) : 128 mm
Depth (without fan) : 146 mm
Height (with fan) : 70 mm
Width (with fan) : 128 mm
Depth (with fan) : 146 mm
Weight (without fan) : 390 g
Weight (with fan/s) : 520 g
Material : Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating
Fan compatibility : 120x120x15 & 120x120x25
Scope of delivery :
-1x NF-A12x15 PWM premium fan
-Low-Noise Adaptor (L.N.A.)
-NT-H1 high-grade thermal compound
-SecuFirm2' mounting kit
-Noctua metal case-badge


FAN Specification
Model : 1x Noctua NF-A12x15 PWM
Bearing : SSO2
Max. Rotational Speed (+/- 10%) : 1850 RPM
Max. Rotational Speed with L.N.A. (+/- 10%) : 1400 RPM
Min. Rotational Speed (PWM, +/-20%) : 450 RPM
Max. Airflow : 94,2 m"/h
Max. Airflow with L.N.A. : 70,8 m"/h
Max. Acoustical Noise : 23,9 dB(A)
Max. Acoustical Noise with L.N.A. : 16,8 dB(A)
Input Power : 1,56 W
Voltage Range : 12 V
MTTF > : 150.000 h
