Features:
• Up to 8 MP Resolution Recording
• Support 1-ch HDMI, 1-ch VGA, HMDI at up to 4K(3840×2160) resolution
• Plug & Play with up to 16 independent PoE network interfaces

Specifications:
Two-way Audio: 1-ch RCA (2.0Vp-p, 1kΩ)
HDMI Output: 1CH Resolution: 1920×1080P/60Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz
Recording Resolution: 8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Audio Output: 1-ch RCA (Linear, 1kΩ)
Synchronous Playback: 16-ch
Recording Resolution: 8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
VGA Output: 1920*1080P/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz
Live view / Playback: 8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
SATA: 4 SATA interfaces for 4HDDs
Hard Disk Capacity : Up to 6TB capacity for each HDD
Network Interface: 1RJ-45 10/100/1000Mbps self-adaptive Ethernet interface
Serial Interface: RS-232; RS-485;
USB Interface: Front panel: 2 × USB 2.0, Rear panel: 1 × USB 3.0
Interface: 16 independent 10/100 Mbps PoE Ethernet interfaces
Working Temperature: -10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF)
Working Humidity: 10% ~ 90%
Chassis: 19-inch rack-mounted 1.5U chassis
Dimensions: 445 × 390 × 70 mm (17.5″× 15.3″ × 2.8″)
Weight(without HDD): ≤ 5 Kg (11 lb)
