GPU : Radeon™ RX 6800 Graphics
7nm GPU
RDNA 2 Architecture
Engine Clock :
Boost Clock: Up to 2360 MHz
Game Clock: Up to 2110 MHz
Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary.

Stream Processors : 4608
Infinity Cache : 128MB
Ray Accelerators : 72
Memory Size/Bus : 16GB GDDR6
Memory Clock : 16 Gbps Effective
Displays : Maximum 4 Displays
Resolution :
HDMI™: 7680×4320
DisplayPort1.4: 7680×4320
Interface : PCI-Express 4.0
Output :
1x HDMI
3x DisplayPort
BIOS Support: Dual UEFI
Game Index : 4K
Cooling :3 Fans
Form Factor : 2.7 slot, ATX
Dimension: 310(L)X 134.3(W)X 55.3 (H)mm
Power Consumption : 350W
OS : Linux®, Windows® 7*, Windows® 10, and Windows 8.1. 64-bit operating system required
*Does not support all features including but not limited to Hardware Raytracing
System Requirement :
Minimum 850 Watt Power Supply
2 x 8-pin Power Connector.
PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard.
Minimum 8GB of system memory. 16GB recommended.
