Technical Specifications
80PLUS® : Gold
Cybenetics Efficiency Level : TBA
Cybenetics Noise Level : TBA
Form Factor : Intel ATX 12 V
Dimensions : 140 mm (L) x 150 mm (W) x 86 mm (H)

Fan Information
Fan Size : 120 mm
Fan Control : Smart and Silent Fan Control
Fan Bearing : Sleeve Bearing
Life Expectancy : 25,000 hours at 40 °C, 15 % - 65 % RH

Cable Information
Modularity : Semi-modular
Cable type : Flat black cables

Electrical Features
Operating Temperature : 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)
MTBF @ 25 °C, excl. fan : 100,000 hours
AC Input : Full Range
Protection : OPP, OVP, OCP, OTP, SCP, UVP

Safety and Environmental
Safety and EMC : cTUVus, TUV, CB, CCC, BSMI, CE, FCC
Environmental Compliance : Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty : 7 Years

Power Output
AC Input Voltage: 100 V - 240 V
Current: 9 - 4.5 A
Frequency: 50 Hz - 60 Hz
DC Output Rail +3.3 V +5 V +12 V -12 V +5 VSB
Maximum Power 20 A 20 A 54 A 0.3 A 3 A
100 W 648 W 3.6 W 15 W
Total continuous power 650 W
