Highlight Features

• H: 120°, V: 13°
• 3 x GE Ports
• Support 3 Power Supply Options: 12 V DC, Passive PoE, 802.3af/at
• One-Touch Pairing for PTMP Mode
• Support TDMA
• Support SON

• Wi-Fi Radio
- Radio design:
- Dual-radio
- 3 spatial streams
- ● Radio 1: 2.4 GHz, 1 spatial stream: 1 x 1, SISO
- ● Radio 2: 5 GHz, 2 spatial streams: 2 x 2, MIMO

- 2.4 GHz channel width: Auto/20/40 MHz
- 5 GHz channel width: Auto/20/40/80 MHz

• Antenna
- Antenna horizontal orientation: 120 degree
- Antenna vertical orientation: 13 degree

• Dimensions and Weight
- Product dimensions (W x D x H): 124 mm x 48 mm x 355 mm (excluding mounting bracket)

• Power Supply and Consumption
- Number of PoE In ports: 1
- Number of PoE/PoE+ In ports: 1

• WLAN
- Bridge speed test: Yes

• Network Management and Monitoring
- SON: Yes
- AI heatmap: Yes
- Restarting devices through Ruijie Reyee App: Yes
- SNMPv1, v2c, and v3: Yes
